energy & DTEC Mining Micro Gas Turbine Set Gas Turbine Power Station Gas Turbine 300KW Genertors

1.0 Sets
MOQ
energy & DTEC Mining Micro Gas Turbine Set Gas Turbine Power Station Gas Turbine 300KW Genertors
Features Gallery Product Description Request A Quote
Features
Specifications
Condition: New
Warranty: 1.5 Years
Applicable Industries: Energy & Mining
Showroom Location: Kazakhstan, Ukraine, Kyrgyzstan, Uzbekistan, Tajikistan
Video Outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: Ordinary Product
Warranty Of Core Components: 1.5 Years
Core Components: Pressure Vessel, Pump, Gear, Bearing, Gearbox, Engine, PLC, Motor
Model Number: GT300
Type: Generator
Electricity Generator Type: Thermal Power
Output Voltage (V): 220
Key Selling Points: Sustainable
Certificate: ISO9001
Efficiency: 35%
Power: 300kw
Pressure Ratio: 15.6
Heat Rate: 11252KJ/kWH
Outputshaft Speed: 11000rpm
Exhaust Flow: 47.5kg/s
After-sales Service Provided: Video Technical Support, Online Support
Local Service Location: Russia, Kazakhstan, Ukraine, Kyrgyzstan, Uzbekistan, Tajikistan
Basic Infomation
Certification: ISO9001
Model Number: GT300
Payment & Shipping Terms
Packaging Details: Standard Export Package
Supply Ability: 10 Set/Sets per Year
Product Description
Product Description

QDR20 heat-electricity co-generation package set

QDR20 heat-electricity co-generation package set
is the high technology and main product of the company. It is recommended and promoted by the State for its advantages of energy saving, environmental protection and resource comprehensive utilization. It is suitable for developing and utilizing of inflammable industrial wasted gases such as coke oven gas, coal bed gas, waste gas of oil field and chemical exhaust gas etc, which are exhausted by metallurgical, petrochemical, coke, and coal field industries. Till now accumulated 40 sets have been delivered to the users and brought the users with mature, stable, reliable and energy saving product.
Output power(KW)
200
The most power (KW)
2330
Steam output
5.5-7.5t/h(0.8 ~1.3Mpa,160 ~300℃)
Heat consumption
15.65MJ/KWh
Output voltage
6.3 or 10.5KV
Frequency
50 Hz
Total heat efficiency
≥ 75%
Cooling water consumption
≤ 3t/h
Soft-water(for boiler)
8t/h

Characteristics

* Invest lower, run cost lower
* Benefit better, invest reclaim time ≤3 years(contain construct time)
* Start-up rapider, from stop to run of all loads, the time＜five minutes.
* Configuration in reason, area is small.
* Heat-electricity efficiency better:Comprehensive efficiency≥ 75%
* Automation extent higher, operation easier. Can automatism carry out start-up, excitation, combine net, power adjust, protect
function, and automatism track record parameter of unit run in 3 minutes.
* Have generate electricity independently and combine net generate electricity capability.
* Fuel hot confine:2300kCal/Nm³~11000 kCal/Nm³.

QDRA70 heat-electricity co-generation package set

QDRA70 gas turbine generating set which adopts Siemens’ SGT200 gas turbine possesses the characteristics of simple design, reliable operation, less emission, and excellent performs. It is able to burn liquid fuel and gas fuel of different kinds. The modular integrated design concept is adopted in the generating set. The modules are assembled as an integrated unit and installed on a standard base after the pre-assembly and the factory testing, which is very convenient for transportation, installation and field maintenance. During industrial power generating, the heat in the high temperature exhaust from the gas turbine can be reused by the heat recovery boiler, which makes the whole comprehensive heat efficiency up to 85%.
Type
QDRA70
Power
6.75MW
Electrical efficiency
31.5%
Heat consumption
11.418MJ/KWh
Turbine speed
11053rpm/min
Pressure ratio
12.2:1
Exhaust flow, temperature
29.3kg/s, 469℃
Output voltage
10.5 or 6.3kv
Steam output
11-14t/h
Fuel
Natural Gas, Coke oven gas, biogas
Nox emissions(with DLE, corrected to 15% O2 dry)
≤ 25ppmV

QDR129 heat-electricity co-generation package set

The core engine of QDR129 generator unit is specially designed for application of electrical power generating purpose, which has two stage power turbines and adopts the updated aerodynamics and combustion technology in the design. It enjoys the compact arrangement, good field serviceability, high reliability, short investment return period, stable and economical power output and strong steam supply capacity. It becomes the first choice of the gas turbine for petroleum and natural gas industry application.
Power Generation
12.90MW
Fuel
Natural gas
Frequency
50/60Hz
Electrical efficiency
34.8%
Heat rate
10.355MJ/KWh
Turbine speed
9500rpm
Compressor pressure ratio
16.8:1
Exhaust gas flow/temperature
39.4kg/s, 555℃
Nox emissions(with DLE, corrected to 15% O2 dry)
＜25ppmV

QY40 supercharging unit

QY40 supercharging unit adopts ST40 gas turbine of P&W Canada company as its power plant and PCL 303 centrifugal compressor technology imported from Italy. The whole set of gas turbine package is controlled by the computer and has world advanced level. It is the best choice for supercharging the natural gas in long distance transportation for the project of “West-east nature gas transmission” in China. QY40 supercharging unit apply to those booster stations which use the natural gas long transport pipes of loss pressure ratio(1.2-1.55),big flow(7 hundred million-14 hundred million).We could also retrofit the compressor with which we can boost for other gas and liquid as per the customers’ request.
Rating transport gas flux
12 hundred million Nm3/a
Gas inlet pressure
3.7 ~4.5MPa
Gas outlet pressure
6.5MPa
Gas inlet temperature
〉40℃
Gas outlet temperature
〉78℃
Run rotate speed
11500~15000r/min
Unit life
30 years
Power
4039KW
Heat efficiency
33.1%
Exhaust flow
13.9kg/s
Exhaust temperature
544℃
Speed of high pressure rotor
29549r/min
Speed of power turbine
14875r/min
Net weight
525kg
General pressure ratio
17.05
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profie
We, Dongturbo Electric Company Ltd.(DTEC). DTEC
is an international corporation, with its headquarter in Chengdu, China, and manufacturing bases in Deyang and Kunming, China, mainly engaged in the manufacturing of power & electric equipments, EPCC (engineering, procurement, construction, commissioning), and export and import business. DTEC also has branches and joint venture in Malaysia, Thailand, and Philippine. Our business scope covers EPC, supply equipment and materials for thermal power inc luding boiler, turbine, generator and their auxiliaries, BOP, electric and C& I etc.; EPC and equipment supply for PV, thermal solar power, Wind & PV hybrid and energy storage system.; spare parts supply and power plant overhaul and maintenance;

We have established close partner relationship with design institute, manufacturers, erection company, traders and end customers both in China and all over the world.

We actively and continuously engaged in the domestic and global electrical markets. Our professional Engineering, Project
Management etc. contributed to the success of the contracted projects, meanwhile, we also shared a lot from those success, we became one of the technical expertise for systematic solution for power industry.
